Somos® PerFORM

Functional Resins

FunctionalHeat resistantStrongHigh detail

This material is ideal for a variety of applications including tooling, wind tunnel testing, high temperature testing, electrical casings, and automotive housings. With the lowest viscosity of any composite stereolithography material, parts made from Somos PerFORM are faster to build, easier to post-process clean, possess superior sidewall quality, and provide unmatched detail resolution.

Print with Somos® PerFORM

Mechanical Properties

Tensile strength65–80 MPa

Tensile modulus9000–10500 MPa

Elongation1.2–2.5 %

Flexural strength110–140 MPa

Flexural modulus9000–10000 MPa

Density1.6 g/cm³

Thermal

Heat deflection at 66 PSI240–260 °C

Print Constraints

Maximum build volume

800 × 800 × 550 mm

Default layer height0.1 mm

Default infill100%

Min embossing0.5 mm

Min engraving0.5 mm

Accuracy± 0.2 mm

Warping riskOver_140_mm

Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard Smooth

1 color

High detailed off-white smooth surface.
