PC-ABS

Composites

StrongHeat resistantFunctionalWater resistant

PC-ABS is a blend of polycarbonate (PC) and acrylonitrile butadiene styrene (ABS) thermoplastics. The result is an FDM filament that exhibits optimal characteristics of each – excellent strength, high toughness and heat resistance, and good flexural strength. Choose PC-ABS when you need the strength of PC but the impact resistance of ABS. PC-ABS is suitable for a variety of applications that include prototyping, tooling, and low-volume production.

Print with PC-ABS

Mechanical Properties

Tensile strength45–70 MPa

Tensile modulus1700–2400 MPa

Elongation5–20 %

Flexural strength60–85 MPa

Flexural modulus1700–2300 MPa

Density1.14 g/cm³

Thermal

Heat deflection at 66 PSI90–110 °C

Heat deflection at 264 PSI80–100 °C

Print Constraints

Maximum build volume

900 × 600 × 900 mm

Default layer height0.2 mm

Default infill20%

Min embossing0.6 mm

Min engraving0.6 mm

Accuracy± 0.4 mm

Warping riskModerate

Interlocking partsNot supported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

3 colors

Standard layered finish in various colors.
