HP® ULTEM 9085

Engineering Plastics

FunctionalFlame retardantChemical resistant

One of the most advanced polymers available on the market, ULTEM 9085's features provide unparalleled resistance, thus the material is suitable for elements operating in the most difficult environment. It offers reduced weight, non-flammability (UL94-V0), durability and high resistance level. ULTEM 9085 meets sectors’ safety standards, e.g. Aerospace: FAR25.853 and OSU55/55; or Railway: EN45545 R6-HL3.

Print with HP® ULTEM 9085

Mechanical Properties

Tensile strength69–86 MPa

Tensile modulus2150–2230 MPa

Elongation4.5–6 %

Flexural strength90–116 MPa

Flexural modulus2126–2500 MPa

Density1.34 g/cm³

Thermal

Heat deflection at 66 PSI158–175 °C

Print Constraints

Maximum build volume

360 × 360 × 415 mm

Default layer height0.2 mm

Default infill20%

Min embossing0.8 mm

Min engraving0.8 mm

Accuracy± 0.3 mm

Warping riskOver_140_mm

Interlocking partsNot supported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

1 color

Standard layered finish.
