FDM TPU

Name: FDM TPU
Brand: Materialize
SKU: f797eb82-7d51-4d32-b82a-0e309332006b
Availability: InStock

Flexible Plastics

FlexibleImpact resistantDurableWear resistant

TPU (thermoplastic polyurethane) spans a wide hardness range, from soft, highly stretchable formulations around Shore A50 to firmer, semi-rigid grades up to Shore D70 that behave more like tough plastics than classic rubber. Across this range, TPU generally offers good abrasion resistance, resists oils, greases, and many common solvents, and retains flexibility in low temperatures where more brittle plastics can fail. Softer grades suit gaskets, seals, and wearable parts that need to stretch and flex repeatedly, while firmer grades suit protective cases, hinges, and components that need only slight give under load.

Print with FDM TPU

Mechanical Properties

Tensile strength26–55 MPa

Tensile modulus9.4–26 MPa

Elongation330–657 %

Flexural strength5–25 MPa

Flexural modulus72–78.7 MPa

Density1.2 g/cm³

Thermal

Heat deflection at 66 PSI40–50 °C

Print Constraints

Maximum build volume

1000 × 1000 × 1600 mm

Min wall thickness1 mm

Min detail size0.8 mm

Default layer height0.2 mm

Default infill20%

Min embossing1 mm

Min engraving1 mm

Accuracy± 0.4 mm

Warping riskModerate

Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Medium Hard (Shore A91-A100)

50 colors

Shore A91-100 TPU is the firmest range on the Shore A scale, feeling closer to a rigid material with some give than to a genuinely soft or cushioning material.

Medium (Shore A81-A90)

14 colors

Shore A81-90 TPU offers genuine flex and cushioning while holding its shape more firmly than the softer ranges. 85A feels similar to a soft shoe insole, and 90A closer to a soft phone case.

Soft (Shore A61-A70)

13 colors

Shore A61-A70 TPU is moderately soft, approaching the firmness of a car tire tread while still meaningfully softer than most FDM TPU filaments.

Very Soft (Shore A50-A60)

12 colors

Shore A50-60 TPU is one of the softest printable hardness ranges, feeling closer to the cushioned part of a shoe sole than to firmer, typical TPU prints.

Very Hard (Shore D51-D70)

4 colors

Shore D51-70 cover hard, wear-resistant plastics, suitable for demanding applications, such as structural supports and gears.

Medium Soft (Shore A71-A80)

7 colors

Shore A71-A80 TPU sits at the firm end of typical shoe-sole hardness, offering noticeably more structure than the softer ranges while still remaining below standard FDM TPU firmness.

Hard (Shore D30-D50)

6 colors

Shore D30-50 marks the entry point into the Shore D scale, used for semi-rigid plastics and hard rubbers.
