Carbon Fiber PEKK

Composites

Chemical resistantHeat resistantImpact resistantFlame retardant

Carbon-reinforced PEKK contains short carbon fibers, which make the material even stiffer and stronger than normal PEKK. Thermal properties remain similar to normal PEKK.

Print with Carbon Fiber PEKK

Mechanical Properties

Tensile strength95–110 MPa

Tensile modulus8000–8465 MPa

Elongation2–3 %

Flexural strength124–142 MPa

Flexural modulus7000–8542 MPa

Density1.39 g/cm³

Thermal

Heat deflection at 66 PSI270–275 °C

Print Constraints

Maximum build volume

250 × 250 × 350 mm

Default layer height0.2 mm

Default infill20%

Min embossing0.8 mm

Min engraving0.8 mm

Accuracy± 0.3 mm

Warping riskLow

Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

1 color

Standard layered finish.

Sanded

1 color

Smooth sanded finish.
