Carbon Fiber ABS

Composites

FunctionalWear resistantStrongWater resistant

CF-ABS is a high-performance ABS filament that is reinforced with carbon fiber, which makes it suitable for anyone who desires a structural component with high modulus, excellent surface quality, dimensional stability, and light weight. It is ideal for applications that can be found in the aerospace, civil engineering, and motor sports industries, which require light weight and rigidity.

Print with Carbon Fiber ABS

Mechanical Properties

Tensile strength46–60 MPa

Tensile modulus2700–5210 MPa

Elongation2–6 %

Flexural strength76–78 MPa

Flexural modulus4700–5300 MPa

Density1.08 g/cm³

Thermal

Heat deflection at 66 PSI78–110 °C

Heat deflection at 264 PSI80–100 °C

Print Constraints

Maximum build volume

1120 × 720 × 620 mm

Default layer height0.2 mm

Default infill20%

Min embossing0.4 mm

Min engraving0.4 mm

Accuracy± 0.3 mm

Warping riskModerate

Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

1 color

Standard layered finish.

Sanded

1 color

Smooth sanded finish.
