BASF® Ultracur3D® EL 60

Functional Resins

DurableFlexibleFunctionalImpact resistant

Ultracur3D® EL 60 is a high-performance elastomer resin engineered for applications requiring flexibility, toughness, and precision. With a Shore hardness of 75 A, it delivers a balance of softness and durability comparable to rubber, making it suitable for seals, gaskets, damping elements, and flexible housings. Parts exhibit excellent tear resistance, rebound behavior, and long-term durability under repeated mechanical stress. In its standard state, the material appears clear with a slightly matte surface, allowing limited visibility of internal structures. Its combination of elasticity, toughness, and high accuracy makes Ultracur3D® EL 60 an ideal choice for functional prototypes and end-use components in automotive, industrial, and consumer applications.

Print with BASF® Ultracur3D® EL 60

Mechanical Properties

Tensile strength8–9 MPa

Tensile modulus47 MPa

Elongation90–100 %

Density1.12 g/cm³

Print Constraints

Maximum build volume

249 × 140 × 495 mm

Default layer height0.1 mm

Default infill100%

Min embossing0.2 mm

Min engraving0.2 mm

Accuracy± 0.2 mm

Warping riskLow

Interlocking partsSupported

Available finishes

Each finish can be combined with the available colors at checkout.

Standard

1 color

Standard BASF® Ultracur3D® EL 60 parts are clear with a slightly matte surface and visible layer lines, combining rubber-like flexibility, tear resistance, and durability straight from the printer.
